Automatic Commercial Dehumidifier Microcomputer Control -model YS-15S
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HUALIAN YIMIN |
| Certification: | CE,ISO |
| Model Number: | YC-15S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1SET |
|---|---|
| Price: | AS NEGOTIABLE |
| Packaging Details: | standard export wooden case |
| Delivery Time: | 60 days |
| Payment Terms: | L/C, T/T, D/A |
| Supply Ability: | 50 sets/month |
|
Detail Information |
|||
| Model: | YC-15S | Power Supply(V/Hz): | 380/50 |
|---|---|---|---|
| Power(Kw): | 7.2 | Current(A): | 11 |
| Weight(Kg): | 260 | Product Name: | Automatic Commercial Dehumidifier |
| High Light: | small commercial dehumidifier,large room dehumidifier |
||
Product Description
Automatic Commercial Dehumidifier Microcomputer Control -model YS-15S
Industrial Dehumidifier YC-15S
Applicable scope of dehumidifier:
power distribution room, electronic room, basement, warehouse, civil air defense project, underground garage, archives room, pharmaceutical factory, drying room, library, storage room, printing factory, painting room, bank vault, food factory, museum, laboratory and other places with requirements on humidity.
The product description
1. Rotary compressor is adopted.
2. Three-minute automatic time-delay protection compressor.
3. Microcomputer control, more accurate control of humidity. Liquid crystal display.
4. Set humidity freely.
5. Beautiful design, plastic steel shell, solid and reliable.
6. Low noise.
7. Automatic cream.
8. The Self - defrosting.
9. Universal wheel sole. Easy to move.
Parameter table
| Model | YC-15S | YC-20S | YC-25S | YC-30S | YC-40S |
| Power Supply(V/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| Power(Kw) | 7.2 | 10 | 12 | 13.8 | 18 |
| Current(A) | 6.0 | 9.0 | 10 | 21.8 | 31 |
| Temperature | 5~38℃ | 5~38℃ | 5~38℃ | 5~38℃ | 5~38℃ |
| Dimension(L*W*H) | 1240X450X1700mm | 1240X450X1700mm | 1240X450X1700mm | 600X1750X2000mm | 650x1850x2100 |
| Weight(Kg) | 260 | 300 | 320 | 380 | 425 |
Purpose of dehumidification
Excessive humidity in the environment is not easy to be discharged in a tight building, while excessive humidity will affect the air quality in the workshop and cause harm to the storage or materials in the workshop. This phenomenon is more serious in the meiyu season in the middle and lower reaches of the Yangtze river. The humidity of the industrial dehumidifier is set between 30% and 90%RH, which can easily remove the excess moisture in the air.
Product advantage:
High quality movement, large air intake, working efficiency far higher than the industry level.
Humidity display, humidity setting, full automation.
Quality assurance, brand compressor, quality assurance.
Automatic defrostingIntelligent low temperature defrosting ensures dehumidification efficiency.
Coarse filter.
Built-in coarse effect filter screen to filter out dust, etc.
Structure and working principle of dehumidifier:
Dehumidifier is by compressor, two (evaporator and condenser), fan, radiator (straight pipes), chassis and controller, its working principle is: the fan will be moist air in the form of negative pressure suction machine, through the compressor refrigeration system will fall below the air dew point temperature of the evaporator surface, the moist air through the evaporator water will break down when the air out and attached to the surface of the evaporator (note: we took a bottle of water from the fridge, like summer, for a moment the bottle there was a layer of condensed water outside the same principle), water will flow down the evaporator on the hydrophilic platinum to drain the water tank to flow into the tank or discharge, Dehumidified dry cold air through the condenser heat recovery after heating the heat will be dry air in a positive pressure way out of the machine, so that the circulation of the wet room to dry effect.
