Stainless Steel 11KW Double Screw Conical Mixer Pharmaceutical
Product Details:
Place of Origin: | CHINA |
Brand Name: | HUALIAN PHARMD |
Certification: | ISO,GMP |
Model Number: | FD-SYH |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Set |
---|---|
Price: | Negotiable |
Packaging Details: | standard wooden case |
Delivery Time: | 50 DAYS |
Payment Terms: | L/C, T/T |
Supply Ability: | 80 |
Detail Information |
|||
Model Number: | FD-SYH | Power(W): | 0.37-11kw, |
---|---|---|---|
VoltageVoltage: | 220v-480v | Loading Capacity(L): | 1200 |
Product Type: | SYH, SYH MIXER | Product Name: | Pharmaceutical Mixing Equipment |
Mixing Precision: | >99.9% | Material: | Stainless Steel |
High Light: | 11kw Double Screw Conical Mixer,Pharmaceutical Double Screw Conical Mixer |
Product Description
Stainless Steel 11KW Double Screw Conical Mixer Pharmaceutical
SYH Three Dimensional Pharmaceutical Blender
Double spiral conical mixer is widely used in the mixing of powders and powders (solid-solid) of chemical, ceramic powder, pesticide, dye, food, color, glaze, feed, building materials and rare earth. Such chemical machinery has wide adaptability to the mixture material, does not cause overheating on the heat sensitive material, does not pressurize and grind the granular material, and does not cause chip separation phenomenon when the material with different specific gravity and particle size is mixed.
Principle:
When it works, the mixer is provided with three-dimensional movement, and carries out revolution and rotation. The mixer has powerful turbulent action to accelerate material flowing and dispersing and makes turning and translational movement to conquer the impact of centrifugal force, so that gravity segregation and agglomeration will not occur in the materials, there is no dead corner, and even mixing is ensured.
Application:
Technical characters:
2. The design of mixing drum is unique. Its inner wall is polished finely. Itsadvantages are no dead corner, no pollution to raw material, convenient indischarge, easy in clean and so on.
Main Technical Parameter:
Type | SYH-5 | SYH-100 | SYH-200 | SYH-400 | SYH-600 | SYH-800 | SYH-1000 | SYH-1500 | |
100 | 200 | 400 | 600 | 800 | 1000 | 1500 | |||
Max loading volume (L) | 4 | 60 | 120 | 240 | 360 | 480 | 600 | 900 | |
Max loading weight (kg) | 5 | 40 | 80 | 160 | 240 | 320 | 400 | 600 | |
Spindle rotatio n speed (r/min) | 24 | 15 | 12 | 10 | 10 | 10 | 10 | 10 | |
Motor power (kw) | 0.37 | 1.5 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | |
Overall dimensions (mm) | L | 600 | 1200 | 1300 | 1500 | 1800 | 1900 | 1950 | 2600 |
W | 1000 | 1800 | 1600 | 2200 | 2400 | 2500 | 2500 | 2500 | |
H | 1000 | 1500 | 1500 | 1500 | 1650 | 2100 | 2350 | 2400 | |
Weight (kg) | 150 | 500 | 750 | 1200 | 1500 | 1650 | 1800 | 2500 |
Structure:
The three-dimensional motion mixer is composed of the machine base, transmission system, electrical control system, multi-direction motion I mechanism, mixing barrel and other parts. The mixing barrel in direct contact with the material is made of stainless steel.The inside and outside walls of the barrel are polished.
Shipping details
The floor plan
